FERRIT Design Bureau Capacities
FERRIT Design Bureau is a Russian developer and manufacturer of electronic equipment of a wide range. Our products are used in television and radio broadcasting, navigation, communications, as well as in scientific research.
FERRIT specialists are ready to propose the development of new radio-electronic equipment and high-complexity equipment. Our laboratories are equipped with modern control and measuring equipment, and also have their own testing base, which allows them to carry out the entire range of electrical tests and tests in terms of external climatic and mechanical influences.
FERRIT specialists are ready to propose the development of new radio-electronic equipment and high-complexity equipment. Our laboratories are equipped with modern control and measuring equipment, and also have their own testing base, which allows them to carry out the entire range of electrical tests and tests in terms of external climatic and mechanical influences.
OUR ADVANTAGES
We are developers and serial manufacturers of microwave technology and various devices
-
High qualityThanks to many years of experience in the field of radioelectronic industry, FERRIT has established itself as a manufacturer of high-quality and reliable microwave devices that are successfully used as part of equipment for various purposes, including in difficult operating conditions.
Our quality service complies with the ISO 90001 standard -
SpeedThanks to the technological base available at FERRIT (vacuum spraying, photolithography, diamond cutting of ferrites, magnets, ceramic substrates), as well as the unification of magnetic circuits and housings, the entire production cycle from receiving an order to shipping products is carried out in the shortest possible time. -
Technical supportWe individually support each project and bring it to the result. You can contact us promptly for advice on the use and operation of microwave devices. -
OpennessYou can see us at industry exhibitions in the region.
We try to provide comprehensive technical information about our products and are ready to help if it is necessary to refine and adapt the products to the customer's requirements. -
FlexibilityUnlike many enterprises engaged only in the production of microwave devices of a limited range, FERRIT carries out its own development of circulators, valves, ballast loads and attenuators in accordance with the customer's technical specifications. -
AvailabilityThe use of FERRIT materials and components of domestic production in the manufacture of products allows you to keep the cost of products low for the end user
Cookies are working on the website!
Cookie Settings
Файлы cookie, необходимые для корректной работы сайта, всегда включены.
Другие файлы cookie можно настроить.
Другие файлы cookie можно настроить.
FERRITE MICROWAVE VALVES AND CIRCULATORS
Technical specifications
Technical specifications
Microwave valves and circulators manufactured by FERRIT allow for round-the-clock reliable protection of the output stages of the transmitter in case of load misalignment.
All products are self-developed and produced directly at our company.
All products are self-developed and produced directly at our company.
Product composition
The magnetic system. All products are equipped with permanent magnets and compensators from leading domestic manufacturers.
Non-interchangeable ferrite node (high frequency part). All elements are manufactured and assembled at Ferrit.
Body. Options are available for both shell-free (built-in) product designs, and in a dust- and moisture-proof enclosure equipped with the required type of connection connectors.
Non-interchangeable ferrite node (high frequency part). All elements are manufactured and assembled at Ferrit.
Body. Options are available for both shell-free (built-in) product designs, and in a dust- and moisture-proof enclosure equipped with the required type of connection connectors.
Features of the range of work
The range of frequencies covered is from 40 to 3200 MHz
Power up to 2 kW
Controlled valve parameters:
- direct losses
- reverse losses (decoupling)
Power up to 2 kW
Controlled valve parameters:
- direct losses
- reverse losses (decoupling)
Technological level
Broadband up to 40%
Drop-In products, the magnetic core serves as a housing, which improves the mass and overall characteristics of the products.
Drop-In products, the magnetic core serves as a housing, which improves the mass and overall characteristics of the products.
MICROWAVE ATTENUATORS, LOADS AND RESISTORS
Technical specifications
Technical specifications
Attenuators, loads, and resistors manufactured by FERRIT Design Bureau are passive microwave devices that reduce the power of the oscillations coming from the current source, and also serve to decouple ultrahigh-frequency circuits from each other, generators with a load, etc.
All products are self-developed and produced directly at our company.
All products are self-developed and produced directly at our company.
Attenuators
Attenuators allow you to measure high power using devices designed for low power.
We try to build a high level of reliability into each of our products. For the ultrahigh frequency range, we manufacture attenuators with constant attenuation and with a smooth change in the attenuation value from 0 to 100-120 dB with a reference accuracy of 0.1—0.5 dB.
We try to build a high level of reliability into each of our products. For the ultrahigh frequency range, we manufacture attenuators with constant attenuation and with a smooth change in the attenuation value from 0 to 100-120 dB with a reference accuracy of 0.1—0.5 dB.
Development and construction
The principle of operation of the attenuator being developed is based on the dissipation of part of the incoming power. This part of the power is converted into heat and passes into the surrounding space. The accuracy of the attenuation measurement is mainly determined by the accuracy of the calibration and readout. In turn, the calibration (attenuation) of many attenuators depends on the ambient humidity.
Selection of attenuators and loads
Attenuators are characterized by the following main indicators: attenuation limits, frequency range, input impedance, or standing wave coefficient, permissible dissipation power, and temperature range.
Our specialists are able to individually approach each technical project and help to find the optimal solution.
Our specialists are able to individually approach each technical project and help to find the optimal solution.
